U-Line 2000 SERIES - Integrated Panel and Grille Installation

U-Line Grill Overlay Installation 12
1/4
8-1/2
3-3/32
19-5/8
1/2
1/2 TYP 3X
5/16 TYP 2X
(7/16 )
5/16
10-5/16
11/64
2-1/8
1/2
22-7/8
23-7/8
FULL R
Grille Overlay Dimensions 24 Inch Models
Grille Drawing 24 inch
