U-Line 2115R Use And Care Guide

2115R, 2175R 13
Door Reversal
Figure 16
Black and white units may be left- or right-hand opening.
Stainless steel unit doors cannot be reversed. The doors
are easily reversed by moving the hinge hardware to the
opposite side. The top hinge hardware will be used on the
bottom of the other side and the bottom hinge hardware
will be used on the top of the other side (Figure 16).
To reverse the door:
Figure 17
1. Remove top hinge screw pin (Figure 17, 1) from door
using a Phillips screwdriver. Remove door by tilting
forward and lifting off bottom hinge pin.
Figure 18
2. Remove plastic screw plugs (three each, top and
bottom)
(Figure 18, 1) from new hinge location. Do
not discard.
3. Remove top hinge (three screws) (Figure 17, 2) and
reinstall hinge screw pin
(Figure 17, 1) .
Figure 19
4. Install the removed top hinge mount on opposite side
BOTTOM
(Figure 19) .
Figure 20
ULIN_0015_A
1
2
ULIN_0003_A
1
ULIN_0002_A
1
ULIN_0005_A
1
ULIN_0004_A
