4-41
Section 4 - Parts
Item Part No. Description
1 2953 Main harness to plug
2 2959 Dual Harness
3 41992 Support, circuit board
(included with 68064)
4 41993 Support, center, circuit
(included with 68064)
5 42122 Screw, wood
6 68092 Thermistor Assembly
7 68084 Main Board
8 68085 Display Assembly, top drawer
9 68086 Display Assembly, bottom drawer
10 21012-BLK Rivet, black
11 26091-02 Sensor cover, black
12 68059-01 Display glass, top drawer
13 68083-01 Display glass, bottom drawer
14 2950-01 Wire connector, 12-pin
15 68080 Jumper switch
(included with 68084)
16 41967-4 Drain tube
Item Part No. Description
17 2694 Dryer (included with 2303-S)
18 2800 Process tube (included with 2303-S
19 2303-S Condenser Assembly
20 11508-02 Drain cup
21 41981 Screw, upper, evaporator
22 41979 Well nut
23 41855-02 Screw, lower, evaporator
24 41158 Nut
25 41156-02 Screw
26 31391-9 Drain trough, black
27 31386 Bushing, black
28 2800 Process tube
(included with 2649-02-S)
29 31213 Spacer
30 21012-BLK Rivet, black
31 2649-02-S Evaporator Assembly
32 2694 Dryer (included with #31)
33 11835 Clamp, control bulb
34 21009 Clamp, cable
Not 31154 Armaflex (included with #31)
Shown
2275DWRWS/2275DWRWOL (2 of 2)
