BUILT-IN INSTALLATION
Your U-Line product has been designed for either free-standing or built-
in installation. When built-in, your U-Line product does not require addi-
tional air space for top, sides or rear. However, the front grille must
NOT be obstructed.
Do not install unit behind closed doors.
Table 3. Built-in Cabinet Dimensions
Unit Dimensions
ABC
34-1/8" 23-15/16" 24"
NOTE
To ease unit installation and removal, it is recommended
that the cabinet rough opening dimensions be increased by
at least 1/4" over the dimensions given for your unit. The
unit must be located to allow clearance for water, drain and
electrical connections in the rear of the ice maker.
A
C
B
CLRCO002a
CAUTION
11
