28
User’s Manual
Figure 33
4. Reinstall front access cover.
5. Reconnect power to ice maker.
6. Empty ice bucket.
GLASS SHELF REMOVAL/INSTALLATION
On units with right-hand hinges, open door fully, grasp shelf firmly, lift
front edge slightly and pull straight out. On units with left-hand hinges,
refer below.
Removal (Figure 34)
1. Pull shelf out about 6" until
back of shelf clears the
“hump” on the right hand
side.
2. Tilt right hand edge of shelf
up.
3. Remove shelf from unit by
pulling out.
SAMPLE AREA
ICE005
3
1
2
CLRCO009A
Figure 34
30005_CLRCO2075 User Manual 8/22/03 4:24 PM Page 28
