15
Install the insert as follows:
Insert edges may be SHARP!
Use care when installing.
1. Remove top hinge screw pin
(7/64" Allen wrench, see
Figure 17). Remove door by
tilting forward and lifting off
bottom hinge pin.
2. Remove two outside screws
holding door handle. Slightly
separate door handle from
door (see Figure 18).
3. Pull door gasket out of
groove (top edge of door
only). Start in the middle and
pull outward, moving toward
the edge (see Figure 19).
This may take some force.
Do not remove the three
screws behind the gasket.
4. Pull handle up and off.
NOTE
Use care not to bend light
switch bracket (where
installed), located on door
bottom when installing door
insert. Do not set door on
bottom edge when pushing
insert into place.
5. Slide custom door panel
insert into 1/4 inch channel
in door front.
