User’s Manual
CUSTOM DOOR PANELS
Two types of custom door panels can be installed on your U-Line unit to
harmonize with or accent the surrounding decor.
FULL OVERLAY DOOR PANEL
A full overlay door panel completely covers the door frame and handle
to give a built-in appearance. See your U-Line dealer for the optional Full
Overlay Door Panel Kit which contains the Panel Preparation Document
for building and installing a full overlay panel. See Table 1 for full over-
lay door panel dimensions.
Table 1. Full Overlay Panel Dimensions
Model A B
2015 Series 29-7/8" 14-3/4"
2075 Series 29-7/8" 23-3/4"
CUSTOM INSERT DOOR PANEL
A custom door panel can be inserted into the door frame to better match
the surrounding decor. Custom door panels can be flat or raised, as long
as the maximum panel thickness where
inserted into the door reveal (channel) is
1/4" thick. For raised panels, the depth
of the reveal is 1/4" on all four sides.
See Table 2 for custom door panel insert
dimensions.
Table 2. Custom Insert Door Panel
Dimensions
Door panel insert must not weigh more than 20 lbs.
Model A B
2015 Series 28–5/32” 14–1/32”
2075 Series 28–5/32” 23–1/32”
B
A
