Page #40 background imageLoading...
Page #40 background image
4-13
Section 4 - Parts
MODEL SS-1095
Item Part No. Description
1 2053 On/Off switch
2 14206-S Door handle
3 31493-1-GRY Gasket, door
4 11698-SS-S Hinge, top
5 11696-SS-S Hinge, bottom
6 80-29017-02 Grille, flush with door
80-29017-01 Grille, flush with cabinet & no frame
7 2628-S Condenser Assembly
8 402 Ice Maker Assembly
150 Face Plate Assembly (See page 2)
9 31429 Ice bucket
10 2182 Inner Liner Assembly/
Evaporator
11 80-17106-03 Door Assembly
12 41785-SS Pivot screw, top
13 41747-SS Pivot screw, bottom
14 2783 Control
15 404-95 Fill Tube Assembly
16 405 Brass Fitting Assembly
17 41254 Plastic Nut & Sleeve
Assembly
18 5401-S Compressor
19 71005 Capacitor
20 41125 Foot, cabinet
21 2964 Dryer
22 5263-S Fan motor
23 5188 Fan blade
24 11444 Back panel
25 1855-1 Power cord
26 31154 Insulator Tube Armaflex
27 2552A Water valve
28 71004 Relay
29 95SS-FRAME Frame, flush to cabinet
29A 95SS-FLUSHFRAME Frame, flush to door assembly
30 26109-S Travel Latch Assembly
31 41941 Screw, hinge
32 71603 Overload
33 41893-ZP Screw, control
34 41342 Screw, back panel
35 41787 Nut, bottom hinge
Not 31021 Grommet
Shown
Not 2819 Process Tube
Shown
