U-Line U-2224ZWC - Wire Diagram

USER GUIDE
Wire Diagram 1
u-line.com
SAFETY • INSTALLATION & INTEGRATION • OPERATING INSTRUCTIONS • MAINTENANCE • SERVICE
Wire Diagram
42349_C WIRING DIAGRAM
115
VOLT
PLUG
220-240 VOLT
PLUG
GROUND: GREEN or GREEN W/ YELLOW
HOT: BLACK (115V) BROWN (220-240V)
NEUTRAL: WHITE (115V) BLUE (220-240V)
(TO COMPRESSOR)
LIGHT BLUE (TO COMPRESSOR)
PURPLE W/ YELLOW
PURPLE
YELLOW
EVAP VALVE
EVAP VALVE
1
10
CONTROL
BOARD
L/T ZONE TEMP
9
1
L/T EVAP
L/T DOOR SWITCH
AMBIENT
R/B DOOR SWITCH
FUSE
6
1
10
5
R/B LIGHT
L/T LIGHT
COND FAN
L/T EVAP FAN
R/B EVAP FAN
R/B ZONE TEMP
R/B EVAP
PROGRAMING
TO DISPLAY
OPEN
ANTENNA
J9
J10
NEUTRAL: WHITE
HOT (LIGHT BLUE)
RELAY
EMBRACO COMPRESSOR
GREEN or GREEN W/ YELLOW
GROUND:
OVERLOAD
115 VOLT
HOT (LIGHT BLUE)
OVERLOAD
EMBRACO COMPRESSOR
220-240 VOLT
RELAY
GREEN W/ YELLOW
GROUND:
NEUTRAL: DARK BLUE
CAP.
CAP.
BROWN BLUE
(TO MULLION HEATER)
ORANGE
[DRAWER MODEL ONLY]
