7 Door Reversal
8 U-Line Product Features
BI95 & BI98
Reversing the Door
All units may be left- or right-hand opening.
Note: The grill
e should not yet be installed. If it has been installed,
remove it for door reversing.
To reverse the door:
1. Remove top hinge from cabinet (three screws). See Fi
gure 1.
Hold door to keep it from falling.
2. Lift the door off the bottom hinge.
3. Remove bottom hinge from cabinet (two screws). See
Figure 2
.
Remove screws on opposite side of cabinet
(Figure 3)
. Note
that there may be a nut behind one or both screws on either
side.
4. Install hinge on opposite side,
b
ottom of cabinet. See
Figure 4
. Replace nut on
back side where installed.
Align hinge outer edge with
cabinet before tightening
screws.
5. Relocate plastic spacer/
bushi
ng on bottom of door
to opposite side, and place
door on bottom hinge pin.
See
Figure 5
. Clean out
bushing hole in door bottom
with a screwdriver if necessary.
6. Remove plastic hole plug from door handle and relocate on
opp
osite side. See
Figure 6
.
7. Remove pivot screw from top hinge, invert screw and reinstall
pivot screw in top hinge. See
Figure 7
.
8. Remove three plastic screw
pl
ugs from hinge holes, top of
cabinet, opposite side. Be
careful not to scratch
cabinet. See
Figure 8
.
9. Place door on lower hinge
pi
n. Invert and install upper
hinge on door.
10. Fasten upper hinge to unit
(thr
ee screws). Partially
tighten screws.
See Figure
9
.
11. Adjust door to assure proper
se
al. Tighten upper and lower
hinge screws securely.
12. Replace three plastic plugs
re
moved in
Step 8
into holes
on top of unit. Replace
screws in holes in bottom of
unit on opposite side.
Plastic
Plug Hole
Plastic
Plug Hole
Hinge
Screw
Right Side
Door Swing
Right Side
Hinge
Invert
Screw
Invert
Hinge
Left Side
Door Swing
6
