Step 11: Front Brake Calliper
Remove the brake calliper spacers from the
front brake callipers, in the same way as instructed
in Step 9a.
a. Attach the front brake calliper to the mounting
detail on the front fork using the supplied
M6 x 18mm bolts.
b. Align the calliper to the front brake rotor and
fasten the two M6 x 18mm bolts.
a.
b.
Step 12: Motor Cable Connection
Front Motor:
a. Thread the front motor cable through the fork
tube clamp. Fix the clamp onto the fork using
one M6 x 20mm bolt, two M6 washers and
one M6 nut.
b. Plug the two ends of cable together, ensuring
they are correctly aligned. Screw the two metal
sleeves together to secure the plug and socket.
c. Use a cable tie to secure the front motor cable
to the cable guard through the two holes at the
front of the cable guard.
c. Fasten the brake line to the cable tie detail on
the fork leg ensuring the brake line is not forced
to bend unnaturally.
