1. Control panel
3. Front case
5. Water level indicator
7. Continuous drainage pipe
9. Wrapping post
11. Filter
2. Top cover
4. Water tank
6. Rear case
8. Rubber stopper
10. Power cord
12. Wheels
Note: if continuous drainage is required, please use a drainage pipe of the following size: 3/8" (10 mm)
diameter
Control Panel and Operation
TimerLow wind Humidity Down
Humidity UpWater Full
Digital displayTimer LampsHigh Wind
The buttons include: High wind button, Low wind button, Timer button, Sleep button, Power button,
Humidity Up button and Down button.
Sleep Power
Functional description
