Ublox NEO-6 User Manual

LEA-6 / NEO-6 / MAX-6 - Hardware Integration Manual
UBX-14054794 Production Information Design-in
Page 38 of 85
17.0 mm [669 mil]
22.4 mm [881.9 mil]
1.0 mm
[39 mil]
0.8 mm
[31.5 mil]
2.45 mm [96.5 mil]
1.1 mm
[43 mil]
3.0 mm
[118 mil]
2.15 mm
[84.5 mil]
0.8 mm
[31.5 mil]
Figure 29: LEA-6 footprint
Stencil: 150  m
15.7 mm [618 mil]
17.0 mm [669 mil]
20.8 mm [819 mil]
0.8 mm
[31.5
mil
]
0.6 mm
[23.5
mil
]
Figure 30: LEA-6 paste mask
12.2 mm [480.3 mil]
16.0 mm [630
mil
]
1.0 mm
[39.3 mil]
0.8 mm
[31.5
mil
]
0.8 mm
[31.5
mil ]
3.0 mm
[118.1
mil
]
1.0 mm
[39.3
mil
]
1.1 mm
[43.3
mil
]
Figure 31: NEO-6 footprint
9.7 mm [382 mil]
10.1 mm [
398
mil
]
1.0 mm
[39.3 mil]
0.7 mm
[
27.6
mil
]
0.8 mm
[31.5
mil ]
0.65 mm
[
26.6
mil
]
1.1 mm
[43.3
mil
]
0.8 mm
[
31.5
mil
]
Figure 32: MAX-6 footprint
Stencil: 150  m
10.4 mm [409.5 mil]
14.6 mm [575 mil]
12.2 mm [480 mil]
0.8 mm
[31.5
mil
]
0.6 mm
[23.5
mil
]
Figure 33: NEO-6 paste mask
Stencil: 150  m
7.9 mm [311 mil]
12.5 mm [492 mil]
9.7 mm [382 mil]
0.7 mm
[27.6
mil
]
0.5 mm
[19.7
mil
]
0.8 mm
[31.5
mil
]
0.6 mm
[23.5
mil
]
Figure 34: MAX-6 paste mask
