Assembly of the Fan4
4
1. Read through all the instructions before starting to use
the fan.
2. Unpack all the parts of the fan the power cable with the
power plug (5). Remove all packaging materials and dispose
of them for recycling.
Make sure that it is standing securely so that it can not tip
or fall over. A safety distance of at least 50 cm from other
objects must be observed.
4. Loosen the four cross recess screws (3) on the underside
of the fan and remove them.
5. First mount the front base (1) on the underside of the
fan and then press the four openings of the rear base (2)
onto the four pegs of the front base (1). The front base (1)
is curved at the top front edge; the rear base (2) has a cable
track (4) on the underside. When mounting the bases, make
sure that the power cable (5) passes through the opening
in the middle of the bases.
6. Attach the front and rear bases (1+2) to the
underside of the fan using the four cross recess
screws. Make sure that the front and rear bases
(1+2) are securely fixed to the fan.
7. Push the power cable (5) through the track (4)
on the underside of the rear base (2) to the outside.
8. Stand the fan upright. Make sure that the power
cable (5) leads through the opening on the rear
base (2) and that the base (1+2) is not resisting on
the power cable (5).
