3.2 Installation Guidelines – Recommended Clearances
It’s also important to remember that infrared heat will reflect off of shiny or bright
surfaces. Heat will be reflected off of mirrors or tile surfaces and fall upon objects you
may not intend to heat.
Although infrared heat does not use a flame or a heating grate, significant heat can be
developed near the filaments and along surfaces on the heater housing. The heater should
not be installed on flammable wall coverings or on surfaces that will deform or discolor when
subjected to heat.
In addition, your heater should be installed
with the following considerations:
• Minimum 71 inches (180 cm) from the
ground when installed on the wall and
95 inches (240 cm.) from the ground
when installed to the ceiling.
• Minimum 16 inches (40 cm) from the
walls when installed on the wall and
28 inches (70 cm.) from the walls when
installed to the ceiling.
• Minimum 40 inches (1meter) from
curtains or other decorations.
• Do not place combustible materials closer than 40 inches (1 meter) in front of the heater.
• Do not place explosive materials closer than 25 feet (7,6 meter) in front of the heater.
WRONG RIGHT
Floor
Min. 40 cm
(16 in)
a
Min. 180 cm
(71 in)
Ceiling
Wall
Min. 240 cm
(95 in)
Min. 70 cm
(28 in)
Wall
Floor
Ceiling
Min. 70 cm
(28 in)
Wall
Ceiling
16 inches 24 inches 28 inches
1800
1800 - 2800 2800
a
Power
Watt
