UHPPOTE HBK-A02 User Manual

6 Wiring Diagram
Common Power Supply Diagram
Special Power Supply Diagram
GND (BLACK)
+12V (RED)
PUSH (GREEN)
NO (BLUE)
COM (WHITE)
NC (BROWN)
OPEN (YELLOW)
BELL
BELL (PINK)
POWER
+12V
GND
-
Fail-safe lock
Fail-secure lock
+
- +
EXIT BUTTON
BELL
+12V
GND
NO
COM
NC
PUSH
Special Power Supply
12VDC
+ -
Fail-safe lock
+ -
Fail-secure lock
EXIT BUTTON
Connect
Connect
BELL (PINK)
GND (BLACK)
+12V (RED)
PUSH (GREEN)
NO (BLUE)
COM (WHITE)
NC (BROWN)
OPEN (YELLOW)
BELL (PINK)
BELL (PINK)
3
EN

UHPPOTE HBK-A02 Specifications

General

Brand	UHPPOTE
Model	HBK-A02
Category	Keypad
Language	English
