ULNA CPE-966 - Application Case

6. Application Case
suitable for extending the network to second buildings, such as garages, shops,
barns,etc.
6.1 Case 1: Point-to-point extended network WiFi range
Computer
Router
Master Bridge
Slave Bridge
Router
Router device(AP mode)
POE POE
6.2 Case 2: Point-to-point extended of surveillance cameras
range
6.3 Case 3: Point-to-multiple point extended surveillance
cameras range
IP Camera
IP Camera
IP Camera
Switch
DVR
Computer
Master Bridge Slave Bridge
DVR
Computer
IP Camera
IP Camera
IP Camera
IP Camera
Master Bridge
Slave Bridge
60°
08
