Ulthera, Inc. Page 45
Recommended Line
Count
The number of lines recommended for the region selected.
Transducer Information
• Transducer type.
• Number of treatment lines remaining/total treatment line capacity of
Energy The energy per TCP being deliv ered. M ay be adjusted with the buttons below.
Length
The length of the treatment line being delivered.
May be adjusted with the buttons
below.
Transducer Types
For planning purposes, toggling these buttons displays the associated treatment
region information on the facial graphic or user regions window being displayed.
The current transducer inserted is the default button selected.
Facial Graphic
The facial graphic
indicates the status of
treatment regions.
An av ailable region is displayed semi-
highlighted and contains the recommended
line count for that region. The number in the center represents the recommended
line count for that region.
A selected region is displayed in white and is outlined with the color of the
transducer being used. The line count in the center represents the running line
count for that region.
A treated region is shown as a solid color of the transducer that was used in that
region with the total lines deliv ered for the region being represented.
A Disabled region is transparent with a light gray border. Disabled regions cannot
be selected.
User Regions Displays a list of regions as defined by the user.
End Treatment
Tap End Treatment followed by Confirm End to end the treatment session.
