GB / IE / NI 7
• Intended use
This power bank with compressor (also referred
to in this manual as the ‘device’ or ‘product’) is
designed to provide additional support to 12 V
vehicle batteries in diesel and petrol vehicles
experiencing start-up problems caused by batter-
ies that are weak, empty or defective� However,
the power bank with compressor cannot replace
the vehicle battery� If no more than 400 A are
needed for starting (max� peak current), the
power bank lets the user single-handedly start the
vehicle when necessary, without additional help
from a third party� The power bank with com-
pressor is also fitted with a USB port� This means
that mobile phones, satnavs or other USB-ena-
bled devices can also be charged if needed� The
integrated compressor is designed to generate
pressure in tyres (e�g� vehicle and bicycle tyres),
balls and other small-scale inflatable articles� Do
not use the compressor to inflate articles with a
large volume, since it can overheat rapidly in
the absence of back pressure� This power bank
with compressor is not designed for continuous
operation to generate pressure of over 3 bar
Any other use may cause damage to the device
and expose the user to a risk of serious injury
The manufacturer is not liable for any injury or
damage resulting from improper use or incorrect
operation� This power bank with compressor is
not suitable for commercial use� Commercial use
will void the guarantee�
This device has been developed for consumer
use and is not suitable for use in a commercial
or industrial environment�
The lamp is not suitable for domestic
room lighting�
-20°C
The LED bulb is suitable for extreme tem-
peratures below -20 °C�
• Features
After unpacking the product, please check that
all of the package contents are present and that
the power bank with compressor is in perfect
condition� Do not use the device if it is defective�
1
Lamp
2
On/off switch for compressor
3
Pressure gauge with pressure display
(not trade-approved)
– In bar: red scale
– In psi: black scale
4
On/off switch for power bank
5
Indicator lights
6
Power bank with compressor
7
Vehicle jumpstart outlet
8
On/off switch for power bank
with compressor
9
Charging port 15 V /1 A
10
USB port 5 V /2 A
11
Jumper cable
12
Clamp lever
13
Valve adapter
a+b: for inflatable items
c: for balls
14
Air hose
15
Connecting valve
16
AC adapter
17
USB cable
• Technical specifications
The three individual cells used to construct the
rechargeable battery are connected in series to
produce a total voltage of 3 × 3�7 V = 11�1 V
and a capacity of 4700 mAh� The battery output
produced in this way is the same as the output
from a rechargeable battery with a total capac-
ity of 14000 maH at 3�7 V
Model: UPK 10 A1
Battery type: lithium-ion
Battery capacity:
14,000 mAh, 3�7 V
Charge cycles: 1,500
Charging time: up to 8 hours
Peak current: 400 A
Starting current: 200 A
Operating temperature: -21 to +55 °C
Voltage: 12 V
