Ultimate TA4600 - Speaker Terminals

3
SPEAKER TERMINALS
Follow the (A/B/C/D+) (A/B/C/D-), channel and polarity markings,
making sure they match the channel and polarity of the connections at
the speakers.
MULTIPLE SPEAKER CONNECTION
PARALLEL- Each additional speaker decreases the load impedance
for the amplifier. The amplifier delivers more current and works
harder.
(+)
(
-
)
+
-
(+)
(
-
)
4 Ohm 2 Ohm
PARALLEL CONNECTION USING 4 OHM SPEAKERS
A
M
P
L
I
F
I
E
R
O
U
T
P
U
T
(A+) (A-) (B+) (B-)
( + ) ( - )
BRIDGE
SPEAKER
(C+) (C-) (D+) (D-)
( + ) ( - )
BRIDGE
SPEAKER
