WORKING PARAMETERS DISPLAY
11
Rotating the roller wheel up or down during charging will switch the
information displayed on the lower half of the LCD screen between
cell voltage, cell IR and working parameters. Cell voltage and IR can
only be displayed during the balance charging process.
10
Temperature
96% 60% 35% 65%
1000mAh
0:30:18
25.00V 2.0A
LiPo 6S ...Charging
4.166V 4.166V 4.166V
4.166V 4.166V 4.166V
1
2
3
4
96% 60% 35% 65%
1000mAh
0:30:18
25.00V 2.0A
LiPo 6S ...Charging
4.166V 4.166V 4.166V
4.166V 4.166V 4.166V
1
2
3
4
96% 60% 35% 65%
1000mAh
0:30:18
25.00V 2.0A
LiPo 6S ...Charging
1
2
3
4
27 C/81 F
17.5V
Battery Cell Count
Battery Type
Working Mode
Battery Voltage
Battery Capacity
Charge/Discharge
Current
Charge/Discharge
Time
Cell Voltage
Percentage of
battery capacity
Input voltage
Scroll the roller wheel
