- The gear selector (9) by pulling it upwards.

Extract:

- The main shaft (10).

- The intermediate shaft (11).

N.B.

LENGTH OF SECONDARY SHAFT

92’2mm (+010 -0,18mm).

11

10

9

47

DISMANTLING THE ENGINE

WORKSHOP MANUAL
