INSTRUMENT PANEL
2
3
5
4
6
1
8
7
1. High Beam Indicator : It will turn on when the
head light is in high beam position.
2.
3.
4. Odometer
: Indicates accumulated distance.
5. Fuel gauge : Indicates fuel level on.
6. Right Directional Light:
al
7.
Neutral light: Indicates when engine is in
neutral and there is no gear engaged.
8.
S
:
RENEGADE II
125 SERIES EFI
19
Check Engine Light: It is normal that it lighting
when you turn on the ignition switch, but once
you turn on the start switch and the engine start,
the check engine light must be turn off, if keeps
it lighting indicate malfunction of the
computerized engine-management system
Left Directional Light: It will turn on when
move the directional switch to the left
