TROUBLE SHOOTING
Transmission clutch slipping
Suction/Intake Syatem/parts leakage
Incorrect Fueling & Ignition Timing adjustments
Cylinder fins/ casting not clean/ clogged with mud, dirt
Silencer/ Exhaust System/ Parts leakage
v
Cooling System/ Parts leakage
Check & correct
Check & correct
Check & correct
Clean the cylinder fins/ casting area
Check & correct
Check & correct
Check & correct
• POSSIBLE CAUSES • ACTIONS TO BE TAKEN
• POSSIBLE CAUSES • ACTIONS TO BE TAKEN
5. Engine overheating
6. Starter motor doesnot work
Ignition Key is OFF
Kill switch OFF
Battery discharge
Fuse blown
Loose connection
Wiring hareness defective
Starter switch not working
Starter relay is defective
Keep ignition key In ON condition
Keep Kill switch in ON condition
It should be more than 12.4 v, Charge if required
Replace if found blown
Ensure the all the connectors are firmly connected to the wiring
Check the continuity of wiring harness starting circuit
Check the continuity
Check the starter relay operation
• POSSIBLE CAUSES • ACTIONS TO BE TAKEN
7. Starter motor operates but engine doesn’t starts
Check engine clutch
check engine starter gear
Ignition system defective
Check spark by removing spark plug, If no spark then check ignition Circuit
Check & rectify
Check & rectify
Ensure the proper gap in spark plug
Spark plug gap adjustment
