Connections
CONNECTIONS CONNECTIONS
Connecting to a Camcorder, Camera or Games Console
TV Source should be set to Video
Audio
R / L
Video
Connecting to a device with SCART output
TV Source should be set to SCART
SCART
OUT
SCART
IN
RF IN
RF OUT RF IN
