Service Manual UPO1000X Series
Instruments.uni-trend.com
3. If you want to reinstall the rear panel, execute the steps in reverse.
Remove Front Panel
The following process is describes the removal and replacement of front panel.
Precondition
• To prevent static damage to the components while working on the instrument, wear properly grounded anti-static
wristbands and foot bands, and use anti-static pads in a tested anti-static environment.
• Take down the knobs on the front panel.
• Remove the rear cover.
• Remove the rear module.
Steps
1. Take down the knobs on the front panel.
