UNI-T UT131 Series - AC Current Measurement Specifications (UT131 A)

UT131 Palm Size Multimeter
-34-
 Input current> 10A , “OL” symbol appears with beeps
 Overload protection 250Vrms
μA mA range：F1 Fuse 0.2 A / 250V Φ 5×20 mm
10 A range： F2 Fuse 10 A /250V Φ 5×20 mm
8. AC Current (only for UT131A)
Range
Mode
Resolution
Accuracy
200.0μA
UT131A
0.1μA
±(1.2%+3)
2000μA
1μA
±(1.2%+3)
20.00mA
0.01mA
±(1.2%+3)
200.0mA
0.1mA
±(1.2%+3)
2.000A
0.001A
±(1.5%+5)
10.00A
0.01A
±(1.5%+5)
