l Connect the test leads to the proper terminals as said above to avoid error
display
. The LCD will display OL indicating diode being tested is open or polarity
is reversed. The unit of diode is Volt (V), displaying the forward voltage drop
readings.
l When diode testing has been completed, disconnect the connection between
the testing leads and the circuit under test, and remove the testing leads away
from the input terminals of the Meter.
Model UT61A/61B/61C/61D/61E: OPERATING MANUAL
28

UNI-T UT61C Specifications

General

Backlight	Yes
Product type	Digital multimeter
Frequency range	0.01 - 10000 kHz
AC current range	0.6 - 10 A
AC voltage range	0.06 - 750 V
DC voltage range	0.06 - 1000 V
Temperature measurement range	-40 - 1000 °C
Dimensions (WxDxH)	87 x 180 x 47 mm
Battery voltage	9 V

Weight and Dimensions

Weight	370 g
