4.1 Function
On switching on of the solenoid drive (800) the solenoid core (207) is pulled against the upper part of
housing (106). The pressure spring (503) is further prestressed and the valve disk (200) opens the
valve cross section. The valve is open.
On shutting off, supply interruption or supply failure the valve closes to the solenoid drive. The valve
disk (200) closes due to the pre-stress of the pressure spring (503). The valve is closed.
4.2 Technical data
Opening times: 0,3 – 0,7s , depends upon nominal width
Closing times:  1s
Solenoid –drive types MG...
Flange DN
Flange ANSI
15
(5N)
1/2
20
(7N)
3/4
25
(10N)
1
32
(12N)
1 1/4
40
(15N)
1 1/2
50
(20N)
2
5 EV...NÜ..92/93
014 014 016 018 019A5 019A2
10 EV...NÜ..92/93
016 016 019A5 018A2 019A1 -
25 EV...NÜA..92/93
016A1 016A1 018A2 019A2 019A3 -
25 EV…NÜA..92/93(#)
018A1 018A1 019A1 - - -
40 EV...NÜA..92/93
019A1 019A1 019A2 020A2 - -
(#) For liquefied gas in its liquid
Connection G
ANSI
1/2
(5)
3/4
(7)
1
(10)
1 1/4
(12)
1 1/2
(15)
2
(20)
100-EVF....
019A5 019A5 - - - -
Flange DN
Flange ANSI
15
(5N)
1/2
20
(7N)
3/4
25
(10N)
1
32
(12N)
1 1/4
40
(15N)
1 1/2
50
(20N)
2
5 EVF...NÜ..92/93
014 014 016 019A5 019A5 019A2
10 EVF...NÜ..92/93
016 016 019A5 018A2 019A1 -
25 EVF...NÜA..92/93
016A1 016A1 018A2 019A2 019A3 -
40 EVF...NÜA..92/93
019A1 019A1 019A2 020A2 - -
40 EVF...NH.Ü..
019A1 019A1 019A2 - - -
100 EVF…N..
- - 019A5 - - -
Drive types with “A” consist of pickup and holding winding
Max. valve loading by pipe power
The indicated moments may not work longer than 10s.
DN 8 10 15 20 25 32 40 50 65 80 100 125 150
Torsion Nm
80 35 50 86 125 160 200 250
1)
325
1)
400
1)
- - -
Bending Nm
35 70 105 225 340 475 610 1100 1600 2400 5000 6000 7600
1)
Not valid in case of valves with flanges
Starting torque, pipe screws greased
DN 8 10 15 20 25 32 40 50 65 80 100 125 150
Torque Nm
20 30 30 30 30 50 50 50 50 50 80 160 160
Starting torque, product screws and nuts greased
Screw M6 M8 M10 M12 M16 M20 M24
Torque Nm
5 11 22 39 70 110 150
4.3 Marking
The type sign on the solenoid drive has the following information:
 Fabricator
 Valve type, nominal width, pressure and temperature indication, fitting position
 Year of construction/ production no.
