Unibor COMMANDO 35 - Motor Parts Identification List

Unibor COMMANDO 35 Manual Original instructions 2019
13
No.
Part Name
Part No.
Qty.
1
Carbon brush assy. 6.3x10x18
eBD002
2
2
Brush holder assy.
eBD001
2
3
Screw m4 x12
eBD003
4
4
Spring Washer m4
eBD004
4
5
Philips head self-tap screw
4.8x45
eBD005
4
6
Back cover
eBD006
1
7
Field coil casing
eBD007
1
8
Field Coil assy. 120v.
eBD008-
a
1
9
Philips head self-tap screw
3.9x60
eBD009
2
10
Baffe
eBD010
1
11
O ring
eBD011
1
13
Dust washer
eBD012
1
12,20
Ball Bearing (8-22-7) 608 2Z
UDC022
3
14
armature assy. 120v
eBD013-
a
1
15
Circlip 28mm x 1.2 B TYPE
eBD014
1
16
Ball Bearing (12-28-8)6001 2Z
UDC023
1
17
Gear case cover
eBD015
1
18
Circlip 10mm x 1 A TYPE
eBD016
1
19
Gasket
eBD017
1
21
Inter shaft assy.
eBD018
1
24
Spindle Gear
eBD019
1
25
Ball Bearing (17-35-10) 6003 2rS
UDC004
1
26
Oil Seal 20-30-7 B TYPE
eBD020
2
27
Gear case
eBD021
1
28
Philips head self-tap screw 4.8 x
60
eBD022
4
29
Ball Bearing 6904 2rS
eBD025
1
30
arbor body.
eBD023
1
31
arbor spring
eBD026
1
32
arbor ejection plug
eBD027
1
33
arbor washer
eBD028
1
34
arbor rubber washer
eBD029
1
35
arbor circlip
eBD030
1
36
Carbon brush washer
eBD031
2
37
Carbon brush fixing screw
eBD032
2
