Unibor COMMANDO 35 - Machine Specifications and Capacity

Unibor COMMANDO 35 Manual Original instructions 2019
5
2. Dispose of the machine and electrical components correctly.
3. Eye protection must be worn when operating the machine.
4. Ear defenders must be worn when operating the machine.
4)SPECIFICATION
Maximum hole cutting capacity in .2/.3C steel = 1.3/8” dia. x 2” deep
Arbor bore = 3/4" dia.
Motor Unit
Voltages
120V 50-60Hz
Normal full load
10 A
Electro Magnet
0.53 A
Size
6-3/8” long
3-3/16” wide
Holding Force at 20°C with 25mm
minimum plate thickness
The use on any material less than 25mm thick will progressively
reduce the magnetic performance. If possible, substitute
material should be positioned under the magnet and work
piece to equate to a suitable material thickness. If this is not
possible, an alternative secure method of restraining the
machine MUST be used.
2000 lbs
Overall Dimensions
Height - minimum
13”
Width (including Capstan fitting)
4-3/8”
Length Overall (including Guard)
13”
Nett Weight
26.5lbs
CMD35
Vibration total values (triax vector sum) in accordance with
EN50144:
Vibration emission value
a W= 1,95 m/s²
Uncertainty(K):1.5m/s²
Level of sound pressure in accordance with EN50144:
LpA: 84 dB(A)
LwA: 97 dB(A)
uncertainty(K)：3dB(A)
Ear and eye defenders must be worn when operating this machine. Wear gloves to protect hands when
operating the machine.
These tools are UK designed and manufactured with globally sourced components and conform to the
requirements of EEC Document HD.400.1 and BS.2769/84
Suitable only for a single phase 50-60Hz A.C. power supply
DO NOT USE ON D.C. SUPPLY
Do not use your magnetic drill on the same structure when arc welding is in progress.
D.C. current will earth back through the magnet and cause irreparable damage.
WARNING: THIS APPLIANCE MUST BE EARTHED!
NB: ANY MODIFICATIONS TO THIS MACHINE WILL INVALIDATE THE GUARANTEE
