23
Tango 0060 11-2019
Re-install outlet
Tango Piston Re-Assembly
Be very careful not to pinch
or roll under the seal edge!
(A damaged seal will cause
the piston to leak and the
Amp draw will be high)
!
Apply a thin layer of
Molykote grease to the brew
chamber
Push the inner piston
straight down into the
brew chamber
!
28
27
30
29
Install the O-ring on the
outside of the brew chamber
Coat the outer O-ring
with Molykote grease
31
32
O-ring in upper grove!
33
Re-install piston
34
