Unic Tango Ace - Page 22

22
Tango 0060 11-2019
Re-attach inner piston
Left hand threads!
Apply a small amount of
Locktite to the threads
Apply a the remaining
IKV-Fluor grease to the jack-
screw shaft
Apply a small amount of
Locktite to the screen screw
Install the screen
Install the 3 screws
19
21
20
26
Tango Piston Re-Assembly
Align screw hole with
the left side slot
(For single piston machine)
Lube new outlet seal
24
22
23
25
Apply a small amount of
Locktite to each screw
18
IKV-Fluor
MPA-0H
Turntable Bearing
Grease NSF
unic-usa.com
