Hand tighten bearing
and nut onto shaft
(Note top race ts into recess)
Install the bearing open side
up. Apply a small amount of
IKV-Fluor grease
Place the top race (larger
hole) groove down
Markings may be dierent
than shown!
Tighten nut until rm
Place the lower race (groove
up) in the cup and apply a
small amount of grease
The upper bearing race has a
larger hole.
Test t the upper race rst
15 mm
15.5 mm
!
Upper
Lower
Tango Turntable Service
Repack and Install bearing
Upper race MUST recess
into turntable holder.
See next page for
proper bearing tension
setting
4
5
3
2
1
6
To Next Page
