COMBINATION LEVER
(LIGHTING SWITCH)
This lighting switch has two modes as follows:
Stage
Light
OFF
① ②
Side marker lights OFF ON ON
Tail lights OFF ON ON
Meter panel OFF ON ON
Head lights OFF OFF ON
NOTE
The above lights can be turned on or off by the
lighting switch regardless of the starter switch.
Remember to turn them off when leaving the truck.
(TURN SIGNAL)
Use the turn signals (front and rear) to indicate the
traveling direction of the truck.
L Left-side lights turn on.
N Off
R Right-side lights turn on.
NOTE
The turn signal lever automatically returns to
•
neutral when the steering wheel is returned to the
straight position.
The turn signal lever may be optionally located at
•
the left side of the steering column.
HORN BUTTON
Press the horn button at the center of the steering wheel
to sound the horn.
The horn sounds regardless of the starter switch
position.
NOTE
Some trucks may have the turn signal lever on the
left side of the steering column.
COMBINATION
LEVER
OFF
HORN BUTTON
2-6
INSTRUMENTS AND CONTROLS
