Unicla UP-150 - Service Tools and Torque Specifications; Service Tool Part Numbers; Bolt Tightening Torque Standards

5.
Service tool part numbers
Bolt torque specications
No. Description Part number
1 Working assembly bench 03301- 00084A
2 Stand, rear mount 03301- 001170
3 Stand, front 03301- 00914A
4 Hub remover, clutch 03301- 000570
5 Pulley pad 03301- 010050
6 Remover, lip seal 03301- 001120
7 Installer, lip seal 03301- 000600
8 Shaft rotating handle 03301- 000610
9 Guide pin 03301- 000360
10 Guide sleeve 03301- 000620
11 Installer, pulley 03301- 000630
12 Socket, 10mm 03301- 000640
13 Socket, 6mm Hex 03301- 000650
14 Clutch wrench 03301- 000660
15 Torque wrench 03301- 000380
16 Snap ring pliers (Shaft) 03301- 000430
17 Snap ring pliers (Hole) 03301- 000420
18 Remover, pulley 03301- 000410
19 Plastic hammer 03301- 000390
20 Thickness guage 03301- 000400
Description Bolt diameter (mm) Tightening torque (N•m)
Housing cap bolts M8 14.7 ± 1
High/low service valve M12 11.7 ± 1
Blind plugs M12 11.7 ± 1
Clutch armature bolts M6 13.7 ± 1
