unicore UM981 User Manual

UM981 User Manual
20 Packaging UC-00-M33 EN R1.0
temperature of 55 degrees Celsius, modules shall be removed from the package during
baking.
Figure 5-2 UM981 Package
-
0.00
1.50
+
0.10
C
P0
P2
B
B-B
B
Dimensions
Po
∅Do
10Po
40.00 0.20
4.00 0.10
E
F
S
1.75 0.10
40.40 0.10
P2
2.00 0.10
W
44.00
0.30
P
24.00
0.10
Ao
17.80
0.10
B0
22.80
0.10
K0
3.30
0.10
t
0.35
0.05
+0.15
1.70-0.05
+0.10
1.50-0.00
C(3:1)
20.20 0.10
Cover Tape
Carrier
Tape
Reel Packaging Diagram
(For Reference Only)
Feed Direction
Reel
∅D1
A
S
W
F
E
330*180*44mm
A-A
A
24
17.8
3.3
0.3
22.8
0.35
Note:
1. The cumulative tolerance of 10 side holes should not exceed ± 0.2 mm.
2. Material of the tape: Black antistatic PS (surface impedance 10
5
-10
11
)
(surface static voltage <100 V), thickness: 0.35 mm.
3. Total length of the 13-inch reel package: 6.816 m (Length of the first part of
empty packets: 0.408 m, length of packets containing modules: 6 m, length
of the last part of empty packets: 0.408 m).
4. Total number of packets in the 13-inch reel package: 284 (Number of the
first part of empty packets: 17; actual number of modules in the packets:
250; number of the last part of empty packets: 17).
5. All dimension designs are in accordance with EIA-481-C-2003.
6. The maximum bending degree of the carrier tape within the length of 250
mm should not exceed 1 mm (see the figure below).
