Description 13
Loudspeaker
The handset has a separate loudspeaker for the loudspeaking function. It is placed on the back
side of the handset.
Microphone
The microphone is placed on the front bottom side of the handset.
Clip
There are two different belt clip options for the handset; a hinge-type clip (standard), and a swivel-
type clip. See "Troubleshooting" on page 66 or "Attach the Swivel-type Clip" on page 65. Use the
clip to attach the handset to a pocket, belt, or similar. It is also possible to use the handset without
any clip on, see "Attach Cover for No Clip" on page 65.
Battery
The battery is a rechargeable Li-Ion battery, placed under a battery cover. See "Replace the Bat-
tery" on page 64.
The battery is fully charged within 2.5 hours. See "Charge the Battery" on page 63.
The battery can be charged separately with a special battery rack charger. See "Charge Spare
Batteries" on page 63.
