PART I: SPECIFICATIONS
7
Technical Specifications
(*) NOTE ON THE BURNER WORKING SERVICE: LMV2x automatically stops after 24h of continuous working. The device immedia-
telystarts up, automatically. LMV3x performs countinuous operation (with electrode only).
Gas categories and countries of application
(*) Premix type ...N burners are not enabled to work with these gas categories.
The above gas groups can be combined according to the standard EN437:2021 and national situation of countries.
BURNER TYPE G258A G335A G380A G400A
Output min. - max. kW
165 - 2580 280 - 3350 295 - 3800 580 - 4000
Fuel MG - Natural gas-Light oil
Category
(see next paragraph)
Gas rate- Natural gas
min.- max. (Stm
3
/h)
17,5 - 273 30 - 354 31 - 402 61 - 402
LPG rate
min.- max. (Stm
3
/h)
6,2 - 96 10,5 - 125 11 - 142 22 - 149
Gas pressure mbar
(see Note 2)
Light oil rate min. - max. kg/h 13,9 - 218 24 - 282 25 - 320 49 - 337
Light oil train inlet pressure
max. bar 2
Light Oil viscosity
cSt @ 40 °C 2 - 7,4
Light Oil density
kg/m
3
840
Power supply triphase
220 V/ 230 V 3~ / 380 V/ 400 V 3N ~ 50 Hz
Auxiliary Power supply
220 V/ 230 V 2~ / 220 V / 230 V 1N ~ 50 Hz
Total power consumption
kW 5,6 7,1 9,1
Pump motor
kW 1,1 1,1 1,1
Electric motor
kW 4,0 5,5 7,5
Protection
IP40
Operation
Progressive - Fully modulating
Gas train 50
Valves size / Gas connection
50 / DN50
Gas train 65
65 / DN65
Gas train 80
80 / DN80
Gas train 100
100 / DN100
Operating temperature °C
-10 ÷ +50
Storage Temperature °C
-20 ÷ +60
Working service
Intermitent
Note1:
All gas flow rates are referred to Stm
3
/ h (1.013 mbar absolute pressure, 15 °C temperature) and are valid for G20 gas
(net calorific value H
i
= 34,02 MJ / Stm
3
); for L.P.G. (net calorific value H
i
= 93,5 MJ / Stm
3
)
Note2: Maximum gas pressure = 360 mbar (with Dungs MBDLE)
= 500 mbar (with Siemens VGD or Dungs MultiBloc MBE)
Minimum gas pressure = see gas curves.
Note3: Burners are suitable only for indoor operation with a maximum relative humidity of 80 %
Note4: with electrode: for safety reasons the burner must stop automatically every 24 hours
Countries Group
AL, AT, BE, BG, CH, CY, DE, DK, EE, ES, FI, FR, GB, GR, HR, HU,
IE, IS, IT, LT, LU, LV, MK, MT, NO, NL, PL, PT, RO, SE, SI, SK, TR
HL (*)
E2R (*)
EK (*) Er (*)
LL (*) E (R)
