PART I: SPECIFICATIONS
7
Technical specifications
NOTE: Choosing the nozzle for light oil, consider Hi equal to 42.7 MJ/kg.
BURNERS RG91 RG92 RG93
Output min - max kW 698 - 2093 849 - 2558 550 - 4100
Light oil rate min - max kg/h 59 - 176 72 - 215 46 - 345
Fuel Light oil
Viscosity cSt @ 40 °C 2 - 7,4
Density
kg/m
3
840
Oil train pressure inlet
bar max 4
Power supply 400V 3N ~ 50Hz
Fan motor kW 4 5,5 7,5
Pump motor kW 1,1 1,1 1,1
Total power consumption kW 5,6
7,1 9,1
Index of protection
IP40
Approx. weight kg 220 220 230
Operation
Progressive - Fully modulating
Operating temperature °C -10 ÷ +50
Storage temperature °C -20 ÷ +60
Working service *
Continuous
BURNERS RG510 RG515 RG520 RG525
Output min - max kW 1314 - 3953 1628 - 4884 2326 - 6977 2000 - 8000
Fuel Light oil
Light oil rate min - max kg/h 111 - 333 137 - 411 196 - 588 169 - 674
Viscosity cSt @ 40 °C 2 - 7,4
Density
kg/m
3
840
Oil train pressure inlet
bar max 4
Power supply 400V 3N ~ 50Hz
Electric motor kW 7,5 11 15 18,5
Pump motor kW 1,1 1,5 1,5 3
Total power consumption kW 9,1 13 17 22
Operation
Progressive - Fully modulating
Index of protection
IP40
Operating temperature °C -10 ÷ +50
Storage temperature °C -20 ÷ +60
Working service
Continuous
WARNING: Burners are suitable only for indoor operation with a maximum relative humidity of 80%
