AC-2100 User Guide 53
2.34bit
As “Sitecode[1byte] + User ID[3bytes]” is sent, the user ID is set
using less than 7 digits.
However, if the user ID consists of 8 digits, Sitecode is ignored
and only “User ID[4bytes] is sent.
Transmission example) SiteCode:001, UID:123456
0 00000001 00000001 11100010 01000000 0
3.Custom As a setting made through user definition, this setting can be set
only at the server. You can only check it at the terminal.
It has nothing to do with the use of a Wiegand type card reader. If it is set to
‘1’ or ‘2’, the following site code value is set.
<Site Code>
(0-255):000
Default setting: ‘000’
This option can be used when the above Wiegand out is set to ‘1’ or ‘2’. Enter a
designated value between 0~255 in a site code to send to the Wiegand port
along with a user ID.
After entering a setting value, press down [F4] button for a longer period of
time to move to the upper menu.
3.8.5. Terminal Initialization
If [5.Initialize] is selected after selecting “6.Device” at the main menu, the
following selection menu is displayed.
1. Init Config
2. Delete Log
3. Init Terminal
[ESC][][][ENT]
Select [1] to initialize setting values,
[2] to initialize authentication records,
and [3] for factory reset.
3.8.5.1. Setting Value Initialization
At default screen [F3~] [6.Device] [5.Initialize] [1.Init Config]
<Init Config>
1.Yes
2.No
[ESC][][][ENT]
Select [1] to initialize,
and [2] to cancel.
UNIONCOMMUNITY
Co., Ltd. / 3F Hyundai Topix Bldg. 44-3 Bangi-dong Songpa-gu
Seoul, Korea (138-050)
Tel : 02-6488-3000 , Fax : 02-6488-3099, E-Mail :sales@unioncomm.co.kr
http
://www.unioncomm.co.kr
