Unitech MS916 User Manual

- 17 -
2.3 BT SPP (Slave)
BT SPP (Slave)
Establishing BT connection in BT SPP (Slave) mode.
1. To establish a BT connection between MS916 and your PC in BT SPP
(Slave) mode, you must install unitech CDC Driver on your PC in advance.
(unitech CDC driver link : http://tw.ute.com/products_info.php?pc1=3&pc2=296&rbu=0&pid=1616 )
2. Use MS916 to scan BT SPP (Slave) barcode.
3. Press Page Down key then press Scan button to enter BT pairing mode.
4. Double-click Bluetooth
®
Device icon in the toolbar on your PC. Select Add
New Devices. When you see a device list windows, choose MS916-XXXX
and then press Next.
5. When PC is establishing a BT connection in BT SPP (Slave) mode with
MS916, windows system will automatically install the required drivers.
6. Back to your PC toolbar, right click on the Bluetooth
®
Device icon, choose
Open Settings. Go to COM Port page and select out-going COM port; for
example COM 27.
7. MS916 will beep when your PC successfully establish a BT connection with
MS916.

Unitech MS916 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	Laser
Scanner type	1D
Read rate (max)	104 reads/s
Linear (1D) barcodes supported	Codabar, Code 128A, Code 32, Code 39, Code 93, EAN-13, EAN-8, MSI
2D (matrix & stacked) barcodes supported	Not supported
Bluetooth version	2.1+EDR
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Certification	CE, FCC, BSMI, VCCI
Keys quantity	3 keys
Product color	White
Internal memory	16 MB
Built-in display	Yes
Housing material	-
Display resolution	128 x 64 pixels
Display technology	OLED
International Protection (IP) code	IP42
Battery capacity	680 mAh
Power source type	Battery
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	95.9 mm
Width	36.9 mm
Height	21.1 mm
Weight	63 g
