Unitech UT-1548 - DIGITAL PID CONTROLLERS UNITECH UT - 1596;1572;1584;1548 INSTRUCTION MANUAL; Features

UNITECH UT - 1596/1572/1584/1548
INSTRUCTION MANUAL Specification
Overview
The UT 15 Series are microprocessor-
based controllers designed with a high
degree of functionality and reliability at a
competitive price. The controllers are
available in different formats: 48x48,
72x72, 96x96 This controller series is
Ideal for the control of temperature,
Humidity, pressure, flow etc.
in a variety of applications including:
z Plastic Processing Industries
z Packaging Machinery
z Painting and coating Plants
z Semiconductor packaging / Testing
z Industrial Dryers
Features
z Easy to Operate
Different configuration levels provide easy
access to parameters.
z Various Control Programming
Several different algorithms are available
as follows:
- PID or ON/OFF Control
- Heat/Cool Control with 2 PID sets
- Motor Position Control
(without slidewire feedback)
z Auto-Tuning Capability
Advanced auto-tuning function calculates
the optimized PID values for your specific
control system.
z
Dual Display and Bar graph
Two large 4 digits display PV, SP and
configuration parameters. One 10 LED
bar-graph displays the control output
(MV), and up to 8 LEDs display the status
of the different outputs (Control, Alarm,
…) and also provide indication of the
Auto/Manual and programmer states.
z Setpoint Programming
Two programs are available with a
maximum of 8 segments. The 2 programs
can be linked together and perform as a
single 16 segment program.
z Extended Alarm Capability
Up to three different alarm outputs are
available per instrument and 17 kinds of
event modes can be assigned to each of
alarm output.
z Communications
RS232 or RS485 (with ASC II & Modbus
RTU Protocol) is optionally available with
a maximum communication speed of
38400 bps.
z
IP65 Front Face Protection
IP65 rated front face permits use in
applications where it may be subjected to
moisture, dust conditions.
z Remote Setpoint Capability
The setpoint can be defined from a
remote PLC or other controller.
z Parameter Lock
A 4-digit security code prevents any
unauthorized changes of parameters or
configurations. Parameters can be hidden
to user to prevent any mis-configuration
of the unit.
DIGITAL PID CONTROLLERS
z And many more......
PV
SV
Model :UT 1596
8
88
8
88
8
88
8
88
OUT OFF AT
AL1
AL2
PV
SV
Model :UT 1177
8
88
8
88
8
88
8
88
OUT OFF AT
AL1
AL2
100%
0%
20
60
40 80
PV
SV
A/M
OUT
AT
AL1
AL2
8
88
8
88
8
88
8
88
Model :UT 1584
PV
SV
Model :UT 1144
OUT
AT
AL1
AL2
8
888
88
8
88
8
88
