Chapter 1 Getting Started
5
Back View
No. Component Description
9. Battery Compartment. Houses the removable and rechargeable 3.7V
2200 mAH Battery Pack.
10. Battery Compartment
Release Latch.
Opens the Battery Compartment.
11. Reset Button. Press the Stylus into the PA600’s Reset Button
to Clean Boot the device.
12. Handstrap. Enables users to securely hold the PA600.
13. Speaker. Enables audio from the PA600.
14. Stylus. Enables users to interact with the operating
system. To use the Stylus, remove it from its holder
and hold it like a pen or pencil.
15. Strap Holder. Secures the handstrap.
16. Memory Card Slot. Accommodates Secure Digital (SD) memory
cards and can serve as an SDIO Port.
17. Bar Code Scanner
Window.
Scans bar codes.
9
10
11
13
15
14
12
16
17
