3. Input
3.1 Define the LNB settings (INPUT > LNB)
o Label: custom label for each input (e.g. VLow, or ASTRA
19.2VLow, …)
o Voltage: The LNB voltage to select the polarization
▪ 13V: Vertical polarization
▪ 18V: Horizontal polarization
o Extended Voltage: Add 1V to the LNB voltage to compensate the
cable losses for long coaxial cables.
o Tone: LNB tone to select low/high band
▪ ON: high band
▪ OFF: low band
o DiSEqC®: control of a DiSEqC® switch (A/B/C/D)
o Band: Satellite band
▪ Ku-band
▪ C-band
o Enable: do not forget to enable the LNB input, this is disabled by
default)
o Press APPLY to confirm the parameters.
