2/12
EX-RC1
Remote I/
O A
dapter
Unitronics
3
Screw-Mounting
The figure below is not
drawn to scale.
It m
ay be used as a gui
de for sc
rew-mounting the m
odule.
Mounting sc
rew type: either M3 or NC6-32.
4mm
5.8mm
(0.2
28")
85mm
(3.346")
80mm
(3.15")
68.4
mm
(2.693")
93mm
(3.66")
4mm (x2)
(0.1
6")
(0.1
6")
2
4
