IO-DI16 I/O Expansion Module 11/00
6 Unitronics Industrial Automation Systems
IO-DI16 Technical Specifications
Max. current consumption 75mA maximum from the adapter’s 5VDC
Typical power consumption
0.2W @ 5VDC
Status indicator
(RUN) Green LED:
—Lit when a communication link is established between module and OPLC.
—Blinks when the communication link fails.
Inputs
Number of inputs 16 (in two groups)
Input type pnp (source) or npn (sink)
Galvanic isolation None
Status indicators (IN) Green LEDs—Lit when the corresponding input is active.
Nominal input voltage 24VDC
Input voltage
pnp (source) 0-5VDC for Logic ‘0’
17-28.8VDC for Logic ‘1’
npn (sink), voltage/current 17-28.8VDC/<1.1 mA for Logic ‘0’
0-5VDC/>4.3mA for Logic ‘1’
Input current 6mA@24VDC
Response time 10mSec typical
Input #15 The specifications below apply when this input is wired for use as a high-speed
counter input/frequency measurer. See Notes 1 and 2.
Resolution 16-bit
Frequency 5kHz maximum
Minimum pulse width 80µs
Environmental
IP20
Operating temperature
0° to 50° C
Storage temperature
-20° to 60° C
Relative Humidity (RH) 5% to 95% (non-condensing)
Dimensions (WxHxD) 80mm x 93mm x 60mm
Weight 141g (4.9oz.)
Mounting Either onto a 35mm DIN-rail or screw- mounted.
Notes:
1. Input #15 can function either as a high-speed counter, a frequency measurer, or as a normal digital
input. When Input #15 is used as a normal digital input, normal input specifications apply.
2. Input #14 can function either as the counter’s reset, or as a normal digital input; in either case, its
specifications are those of a normal digital input.
