UMI-B1 UL Series Inverter Appendix B Dimension drawings
136
Model
W1
H1
H3
H4
D1
D2
Installation
hole (d)
UMI-0004BU-B1
80.0
160.0
35.4
36.6
123.5
120.3
5
UMI-0007BU-B1
80.0
160.0
35.4
36.6
123.5
120.3
5
UMI-0015BU-B1
80.0
185.0
35.4
36.6
140.5
137.3
5
UMI-0022BU-B1
80.0
185.0
35.4
36.6
140.5
137.3
5
UMI-0007EU-B1
80.0
185.0
35.4
36.6
140.5
137.3
5
UMI-0015EU-B1
80.0
185.0
35.4
36.6
140.5
137.3
5
UMI-0022EU-B1
80.0
185.0
35.4
36.6
140.5
137.3
5
