Unitronics UMI-B1 UL Series User Manual

UMI-B1 UL Series Inverter Product overview
10
2.3 Name plate
Figure 2-1 Name plate
2.4 Type designation key
The type designation contains information on the inverter. The user can find the type
designation on the type designation label attached to the inverter or the simple name
plate.
UMI – 0022 – E – U – B – B1
① ② ③ ④ ⑤ ⑥
Figure 2-2 Product type
Key
No.
Description
Detailed content
Product line
①
Abbreviation for
product line
UMI for Unitronics Inverters
Rated power
②
Power range
0004:400W
0022:2.2kW(3HP)
Voltage degree
③
Voltage degree
B: 1PH 200V–240V
C: 3PH 200V–240V
E: 3PH 380V–480V
Certification
④
Certification
U: UL
Optional
Braking unit
⑤
Optional Braking
unit
B: Built-in braking unit.
Product series
⑥
Product series
B1: for B1 Series Inverter Family
