Unitronics US5-B5-RA28 - Page 16

UniStream
®
Built-in
16
Unitronics
RTD
NOTE
 When connecting 3- or 4-wire RTDs, make sure to use conductors of the same
type, width, and length for all RTD wires, otherwise the accuracy will degrade.
 When connecting 4-wire RTDs, use 3-wire cable and leave the unused wire
unconnected and of minimal length.
2-wire
3-wire
4-wire
